大幅面高宝利必达145/164

新一代印刷机,新的性能维度:大幅面利必达

高宝之所以被誉为大幅面单张纸胶印机领域中的市场和技术领导者是有诸多原因的。时至今日,许多源自高宝的开拓性创新仍然是独一无二的。利必达145和164系列印刷机已在其各自的幅面级别中树立了行业标杆。高达每小时18,000张的生产速度,快速的印刷准备,极高的自动化水平和精确的联机质量控制系统,共同为高效和可盈利的生产打下了坚实的基础。

Rapida145/164.pdf
pdf, 3290 KB

主角闪亮登场!请观看视频

Rapida 145 & Rapida 164亮点

  • 紧凑节省空间的设计降低投资成本
  • 为客户特定的配置从而节省成本效益的在线生产
  • 完全自动化同步印刷准备过程
  • 现代且直观的操作系统
  • 印刷性能和准备时间与3B幅面相似

自动化功能为最快的印刷活件转换

结合了一系列引领潮流的创新,Rapida 145和Rapida 164系列在其相同幅面领域中是独一无二的。以下三个标准是实现如此卓越性能的关键:极短的印刷准备时间,快速且高度自动化的活件转换,最大的可用性和最高的产能。无论您主要是印刷短版活和中版活还是专门印刷超长版活,您都始终可以信赖利必达大幅面印刷机。此外,联机控制系统具有扩展到印张检查和连续生产监控的功能,可以确保始终一致的一流印刷质量。

18000 Bogen / Stunde im Großformat

利必达大幅面系列独具的创新装置:

  • DriveTronic SIS:无侧规进纸装置
  • DriveTronic SPC:在所有印刷机组中同时进行的换版
  • 预登记和印版识别
  • DriveTronic SFC:在印刷机组中与其它印刷准备过程同时进行的自动上光版更换
  • 用于快速网纹辊更换的AniSleeve技术
Rapida 145

你对更多细节感兴趣吗?产品信息

Compact, space-saving design reduces investment outlay

The large-format Rapidas are the ideal choice where high performance is required, but space is at a premium. For an equal or marginally larger print format, they occupy significantly less floor space than competitor presses. That reduces space and production costs. The Rapida 145 and Rapida 164 are also well positioned for installation in printshops with low ceiling heights.

Another important aspect is that large-format presses from Koenig & Bauer eliminate all unnecessary weight. That reduces the necessary construction outlay. Depending on the configuration, a Rapida may weigh up to a third less than other comparable presses.

With regard to energy consumption, too, the Rapida 145 and Rapida 164 stand above the crowd with significantly lower connected loads both for the press itself and for the IR/hot air drying. This is especially true when using the VariDryBlue technology. Koenig & Bauer is furthermore the first manufacturer to offer LED-UV dryers in large formats. In other words, the large-format Rapidas also place cutting-edge ecological technology at your fingertips.

Rapida 145 Koenig & Bauer

Perfectly automated, simultaneous makeready processes

Wherever possible, individual makeready steps are integrated into the essentially automated simultaneous job changeover process. Washing, for example, runs parallel to the plate and coating forme change. CleanTronic Synchro possesses two separate washing beams, enabling impression cylinders and blankets to be washed simultaneously. Alternatively, the washing time can be reduced by 50 per cent if both washing beams are applied to the blanket.

With SPC, the time required for plate changes is reduced to a minimum. Plate changes are performed simultaneously in all units, and furthermore parallel to other makeready processes; they thus have no influence whatsoever on overall makeready time. DriveTronic PlateIdent detects the plates mounted for a new job, takes care of pre-registration, and checks whether the plate is at the correct position on the press.

DriveTronic SFC enables also coating forme changes to be performed parallel to plate change and the selected washing functions. If, on a double-coating press, only one coater is required for a particular job, makeready can even be completed on the second tower while production is running. With the AniSleeve system, anilox roller replacement could hardly be easier – the whole process can be handled by a single person, and that simultaneously with other processes.

AniSleeve Technology

Highly sophisticated, customer-specific configurations

Notwithstanding a considerable number of installations with commercial, book and magazine printers, large-format Rapidas are most commonly employed in packaging applications. Raised press foundations, automatic non-stop pile changing, pile logistics, inline coating and appropriate dryer installations are typical features of a packaging press. Facilities for single and multiple coatings, if necessary also before the actual printing, as well as cold foil application and perfecting, permit highly individual product refinement.

Thanks to the high level of automation, which provides a basis for economical production even with short runs, the large-format Rapidas are a no less interesting means of production for books, magazines and the full spectrum of commercial products. Similarly for standardised commercial printing with gang formes, as practised by Internet printers. This is a field in which perfector models come into their own, including configurations for 4-over-4 production.

Various special applications enable offset printing on less conventional substrates such as beer mats or metal sheets. The MetalStar presses offered by Koenig & Bauer MetalPrint, for example, also incorporate printing units and other press assemblies of the large-format Rapidas.

Rapida 145 Großformat Bogenoffset
Standard Optional
max. sheet format 1060 x 1450 mm -
max. production speed 15.000 sheets/h up to 18.000 sheets/h
Substrate thickness 0,1 - 0,7 mm 0,06 - 1,6 mm
Printing units 2 - 10 10+
Sidelay-free infeed DriveTronic SIS -
Fully automatic plate change FAPC -
Perfecting -
Simultaneous forme change DriveTronic SFC -
Simultaneous plate change DriveTronic SPC -
Fully automatic anilox roller change AniSleeve -
CleanTronic washing systems -
VariDry dryer systems -
AirTronic delivery with dynamic sheet brake -
Logistics solutions -
ErgoTronic console with TouchTronic interface -
Quality measurement and control systems -
Remote maintenance module PressSupport 24 Sheetfed -
Workflow solutions for printshop networking -
Standard Optional
max. sheet format 1205 x 1640 mm -
max. production speed 15,000 sheets/h up to 17,000 sheets/h
Substrate thickness 0.1 - 0.7 mm 0.06 - 1.6 mm
Printing units 2 - 10 10+
Sidelay-free infeed DriveTronic SIS -
Fully automatic plate change FAPC -
Perfecting -
Simultaneous forme change DriveTronic SFC -
Simultaneous plate change DriveTronic SPC -
Fully automatic anilox roller change AniSleeve -
CleanTronic washing systems -
VariDry dryer systems -
AirTronic delivery with dynamic sheet brake -
Logistics solutions -
ErgoTronic console with TouchTronic interface -
Quality measurement and control systems -
Remote maintenance module PressSupport 24 Sheetfed -
Workflow solutions for printshop networking -
